Saving Curves onto a 1520

Joined
May 5, 2022
Messages
33
A bit off topic but anyone where to find DOS Oscilloscope Software that would work on a 286 1520? I have looked a bit but so far, no luck.
If anyone is curious that is a tube trace of a 3AU6 tube on a Tek 577D1 which doesn't have a serial port (it's from 1972), but I am hoping to save waveforms/analyze off of my 222a or TDS 420a (not pictured) using my 1520.
Thanks!


Attachments

  • IMG_1311.JPEG
    911 KB · Views: 13
  • IMG_1309.JPEG
    904.1 KB · Views: 13

NeXT

Veteran Member
Joined
Oct 22, 2008
Messages
7,102
Location
Kamloops, BC, Canada
Well the 222A has some sort of a "comm port" but to me that's really odd because almost every scope I know of was using GPIB to communicate between devices. Can't really help you there.
The 577D1 has that, but the GRiD 1520 isn't like the Compass and doesn't have GPIB onboard.
I know there was a time many many years ago where "mini scopes" were advertised in the back of magazines that plugged into the serial or parallel port and supported DOS but I have never actually seen one in reality.

Joined
May 5, 2022
Messages
33
Well the 222A has some sort of a "comm port" but to me that's really odd because almost every scope I know of was using GPIB to communicate between devices. Can't really help you there.
The 577D1 has that, but the GRiD 1520 isn't like the Compass and doesn't have GPIB onboard.
I know there was a time many many years ago where "mini scopes" were advertised in the back of magazines that plugged into the serial or parallel port and supported DOS but I have never actually seen one in reality.
Thanks, but as I mentioned earlier my 577D1 doesn’t have a serial or gpib out and I would need a add on mod (they do exist for usb at least) for the traces to be saved. For the 222 it looks like I would need some software that I have been unsuccessful in finding the analysis software (like CAT200) thus far.
I did find the basic terminal program however (https://www.tek.com/en/support/software/utility/222-power-scout-utility-software)


Attachments

  • image.jpg
    2.3 MB · Views: 5
Last edited:
Joined
May 5, 2022
Messages
33
Sorry, I meant the TDS 420a has GPIB.
NP, I was able to get that terminal software running on my 1520 and printed out some sample waveforms. However, I ordered a breakout box because the rs232 requires a specific pinout in the 222a for actual communication with the scope.
I would be very happy to be able to non-destructively add a mod to my 577d1 that allows a similar capture, but it would be significantly harder because it's an analog instrument (would require digitizing...)


Chuck(G)

25k Member
Joined
Jan 11, 2007
Messages
40,294
Location
Pacific Northwest, USA
Given the vintage of this thing, it's pretty clear that there aren't any external outputs. It seems that your best option is what we used to do back in the day on our 7000 series scopes--a Polaroid 'scope camera. Since they're not really used any more, such cameras are very cheap on the used market.

At least one fellow has worked up a digicam attachment for his old scope: https://hackaday.io/project/171961-a-digital-camera-for-analog-oscilloscopes

Joined
May 5, 2022
Messages
33
Given the vintage of this thing, it's pretty clear that there aren't any external outputs. It seems that your best option is what we used to do back in the day on our 7000 series scopes--a Polaroid 'scope camera. Since they're not really used any more, such cameras are very cheap on the used market.

At least one fellow has worked up a digicam attachment for his old scope: https://hackaday.io/project/171961-a-digital-camera-for-analog-oscilloscopes
Cool! I will check it out
These guys on eBay also sell a USB attachment mod but it's too expensive for me to consider (960$!)


Chuck(G)

25k Member
Joined
Jan 11, 2007
Messages
40,294
Location
Pacific Northwest, USA
The price on that one is now 1 cent short of USD$4000.00!
Probably just a MCU with a couple of DACs. But hey, given the small market, maybe it's worth it.

Joined
May 5, 2022
Messages
33
The price on that one is now 1 cent short of USD$4000.00!
Probably just a MCU with a couple of DACs. But hey, given the small market, maybe it's worth it.
To be fair that includes the curve tracer as well but yes.
Below it says they will sell the usb device separately for 960$.
Based upon where it hooks up it seems as though it just draws off of the CRT control grid for digitization.

Joined
May 5, 2022
Messages
33
I was able to get the 222a to communicate with the 1520 using that software.
For anyone interested, here is the step generator output for a 577d1.


Attachments

  • IMG_1339.jpeg
    720.6 KB · Views: 5
